LF230-G
LF230-G
System Rated Voltage (V)：124.8
Max. Charging Current (A)：230
System Energy (kWh)：28.7
Single Pack Dimensions (mm)：920 × 630 × 240
Single Box Weight (kg)：184
Specific Energy (Wh/kg)：≥160.1
Thermal Management：Heating Film / Natural Cooling or Liquid Cooling
Operating Temperature (°C)：-30 ~ 60
IP Protection Rating：IP68
Specifications
| Cell Model | Series-Parallel Configuration | Single-Branch | Dual-Branch | |||||||
| Pack Voltage (V) |
Series Count (S) |
Energy(kWh) | Battery Box Configuration |
Number of Battery Boxes |
Number of Cells |
Energy(kWh) | Battery Box Configuration |
Number of Battery Boxes |
Number of Cells |
|
| LF230 | 499.2 | 156 | 114.82 | 4G | 4 | 156 | 229.63 | (4G)*2 | 8 | 312 |
| LF230 | 528 | 165 | 121.44 | 1C+3G | 4 | 165 | 242.88 | (1C+3G)*2 | 8 | 330 |
| LF230 | 556.8 | 174 | 128.06 | 2C+2G | 4 | 174 | 256.13 | (2C+1G)*2 | 8 | 348 |
| LF230 | 585.6 | 183 | 134.69 | 3C+1G | 4 | 183 | 269.38 | (3C+1G)*2 | 8 | 366 |
| LF230 | 614.4 | 192 | 141.31 | 4C | 4 | 192 | 282.62 | (4C)*2 | 8 | 384 |
| LF230 | 624 | 195 | 143.52 | 5G | 5 | 195 | 287.04 | (5G)*2 | 10 | 390 |
| LF230 | 652.8 | 204 | 150.14 | 1C+4G | 5 | 204 | 300.29 | (1C+4G)*2 | 10 | 408 |
