LF304-C
LF304-C
System Rated Voltage (V)：115.2
Max. Charging Current (A)：304
System Energy (kWh)：35.02
Single Pack Dimensions (mm)：1060 × 630 × 240
Single Box Weight (kg)：222
Specific Energy (Wh/kg)：≥160.04
Thermal Management：Heating Film / Natural Cooling or Liquid Cooling
Operating Temperature (°C)：-30 ~ 60
IP Protection Rating：IP68
Specifications
| Cell Model | Series-Parallel Configuration | Single-Branch | Dual-Branch | |||||||
| Pack Voltage (V) | Series Count (S) | Energy (kWh) | Battery Box Configuration | Number of Battery Boxes | Number of Cells | Energy (kWh) | Battery Box Configuration | Number of Battery Boxes | Number of Cells | |
| LF304 | 480 | 150 | 145.92 | 5G | 5 | 150 | 291.84 | (5G)*2 | 10 | 300 |
| LF304 | 499.2 | 156 | 151.76 | 1C+4G | 5 | 156 | 303.51 | (1C+4G)°2 | 10 | 312 |
| LF304 | 518.4 | 162 | 157.59 | 2C+3G | 5 | 162 | 315.19 | (2C+3G)*2 | 10 | 324 |
| LF304 | 537.6 | 168 | 163.43 | 3C+2G | 5 | 168 | 326.86 | (3C+2G)*2 | 10 | 336 |
| LF304 | 556.8 | 174 | 169.27 | 4C+1G | 5 | 174 | 338.53 | (4C+1G)*2 | 10 | 348 |
| LF304 | 576 | 180 | 175.10 | 5C | 5 | 180 | 350.21 | (5C)*2 | 10 | 360 |
| LF304 | 595.2 | 186 | 180.94 | 1C+5G | 6 | 186 | 361.88 | (1C+5G)*2 | 12 | 372 |
| LF304 | 614.4 | 192 | 186.78 | 2C+4G | 6 | 192 | 373.56 | (2C+4G)*2 | 12 | 384 |
| LF304 | 633.6 | 198 | 192.61 | 3C+3G | 6 | 198 | 385.23 | (3C+3G)*2 | 12 | 396 |
| LF304 | 652.8 | 204 | 198.45 | 4C+2G | 6 | 204 | 396.90 | (4C+2G)*2 | 12 | 408 |
